Product |
Seamless Structural Pipe, Structural Tube and Pipe, A500 Round Structural Pipe |
Application |
Used in the general structure and the mechanism Industry |
Size |
OD: 10.3-762mm |
|
WT: 6-35mm |
|
LENGTH: 5.8/6/11.8/12m |
Pipe Type |
Round, Square, Rectangle, Hydraulic, Honed Tubes |
Pipe Standard |
ASTM A53 ASTM A519 ASTM A500 ASTM A252 |
|
JIS G3441/G3445 |
|
EN 10210/10297 |
Common types |
Seamless Steel Pipe, ERW Steel Pipe, Spiral Steel Pipe |
|
DSAW Carbon Steel Pipe, Fence Pipe, Culvert Pipe |
In general, structural pipe is a type of steel construction pipe that meets certain standards of chemical composition and mechanical properties.
This pipe can be used for a wide variety of structural applications and there are variety of types of structural pipe available.
Structure seamless steel pipe is intended for mechanical and pressure applications and is also acceptable for ordinary uses in steam, water, gas, and airlines.
It is suitable for welding and suitable for forming operations involving coiling, bending, and flanging, subject to certain qualifications.
Common types of structural pipe include:
Seamless Steel Pipe: Seamless steel structural pipe is a durable pipe product that is commonly used for dock piling, pipe piling, caissons, and bollards.
ERW Steel Pipe: This structural pipe is typically known to the construction industry as high quality line pipe and it is commonly used by the oil and utility companies. This steel pipe can be used for sign pole, column, dock, and tunnel construction.
Spiral Steel Pipe: This is an economical and durable type of structural pipe that offers long lasting durability for things like road casing, piling and trenches.
DSAW Carbon Steel Pipe: This structural pipe is welded on both the OD and the ID. It is available in many different grades and is used for road casing, road boring, culverts, and more.
Fence Pipe: This is a type of structural pipe that is becoming popular for building fences because of its high durability and strength. This structural pipe is used for enclosing parks, parking lots, and more.
Standard Structural Steel Pipes & Tubes Specifications & Grades
ASTM A53/ASME SA53 Grades A & B;
ASTM A519/ASME SA519 Grades 1020,1026,4140,4142;
ASTM A252/ASME SA252 S235JRH, S275JOH, S275J2H, S355JOH, S355J2H, S355K2H;
ASTM A500/ASME SA500 Grades A, B, C, D;
EN10297-1 Grades E235, E275, E315, E355;
EN10210-1 Grades S235JRH, S275JOH, S275J2H, S355JOH, S355J2H, S355K2H;
Structural Pipe Applications
Structural pipe can be used for a variety of different applications including:
l Columns
l Sign Poles
l Structural Supports
l Pilings
l Bollards
l Roadway Billboard Signs
l Tower Construction
l Caissons
l Road Bore Casings
l Dock Piles
l Dredge Pipe
l Slurry Lines
l Bumper Posts
Specification
Size Range |
6NB to 1200NB IN |
Schedule |
. 5, 10, 20, 30, 40, 60, 80, 100, 120, 140, 160, XXS. |
Pipe Type |
Round, Square, Rectangle, Hydraulic, Honed Tubes |
Length |
5.8/6/11.8/12m,Single Random, Double Random & Cut Length |
End |
Plain End, Beveled End |
Stainless Steel Seamless Structural Pipe Dimension
Type |
Seamless steel pipe |
Specification |
114-914MM×4-60MM |
Diameter |
114MM-914MM |
Thickness |
4MM-60MM |
Length |
5.8/6/11.8/12m,According to your requirements |
Special pipe |
Regular and special thick-walled structure steel pipe, maximum thickness of up to 60MM |
Process |
Hot rolled and hot expanded |
Application |
Our high quality structure steel pipes are highly sought after by customers from supplying, petroleum, natural gas, transportation and construction industries. |
Stainless Steel Seamless Structural Pipe Standard
Standard |
GB/T 8162—2008, GB/T 8163—2008, ASTM A106 Gr.B, ASTM A53 Gr.B, ASTM A210, ASTM A333, DIN1629, DIN2448, DIN17175, EN10216, EN10204, EN10297 etc. |
Material |
20#, Q345B, ST52, S355JRH, ST37, 10#, A106/A53 GR.B |
Application & Specification (Seamless)
Oil & Gas Sector |
|
API |
5L |
API |
5CT |
IS |
1978, 1979 |
Automotive Industry |
|
ASTM |
A-519 |
SAE |
1010, 1012, 1020, 1040, 1518, 4130 |
DIN |
2391, 1629 |
BS |
980, 6323 (Pt-V) |
IS |
3601, 3074 |
Hydrocarbon Process Industry |
|
ASTM |
A-53, A-106, A-333, A-334, A-335, A-519 |
BS |
3602,3603 |
IS |
6286 |
Bearing Industry |
|
SAE |
52100 |
Hydraulic Cylinder |
|
SAE |
1026, 1518 |
IS |
6631 |
DIN |
1629 |
Boiler, Heat Exchanger, Superheater & Condenser |
|
ASTM |
A-179, A-192, A-209, A-210, A-213, A-333, A-334,A-556 |
BS |
3059 (Pt-I Pt-II) |
IS |
1914, 2416, 11714 |
DIN |
17175 |
Railways |
|
IS |
1239 (Pt-I),1161 |
BS |
980 |
Mechanical, Structural General Engineering |
|
ASTM |
A-252, A-268, A-269, A-500, A-501, A-519, A-589 |
DIN |
1629, 2391 |
BS |
806, 1775, 3601, 6323 |
IS |
1161, 3601 |
ASTM A53 |
Standard Specification for Pipe, Steel, Black and Hot-Dipped, Zinc-Coated, Welded and Seamless |
ASTM A519 |
Standard Specification for Seamless Carbon and Alloy Steel Mechanical Tubing |
ASTM A500 |
Specification for Cold-Formed Welded and Seamless Carbon Steel Structural Tubing in Rounds and Shapes |
ASTM A252 |
Standard Specification for Welded and Seamless Steel Pipe Piles |
